B-CUBE NEW ZD680 6C PRO M8N/M9N/M10 Full Carbon Fiber Hexa-Rotor Foldable Arm Hexacopter Frame Kit PIXHAWK with Unflodable Landing Gear
B-CUBE NEW ZD680 6C PRO M8N/M9N/M10 Full Carbon Fiber Hexa-Rotor Foldable Arm Hexacopter Frame Kit PIXHAWK with Unflodable Landing Gear
Couldn't load pickup availability
PIXHAWK 6C PRO
The Pixhawk® 6C PRO is the latest update to the successful family of Pixhawk® flight controllers, based on the Pixhawk® FMUv6C Open Standard and Connector Standard. It comes with PX4 Autopilot® pre-installed. STMicroelectronics® based STM32H743, paired with sensor technology from Bosch® & InvenSense®, giving you flexibility and reliability for controlling any autonomous vehicle, suitable for both academic and commercial applications.
The Pixhawk® 6C PRO's H7 microcontroller contain the Arm® Cortex®-M7 core running up to 480 MHz, has 2MB flash memory and 1MB RAM. Thanks to the updated processing power, developers can be more productive and efficient with their development work, allowing for complex algorithms and models.
The Pixhawk 6C PRO includes high-performance, low-noise IMUs on board, designed to be cost effective while having IMU redundancy. A vibration isolation System to filter out high-frequency vibration and reduce noise to ensure accurate readings, allowing vehicles to reach better overall flight performances.
The Pixhawk® 6C PRO is perfect for developers at corporate research labs, startups, academics (research, professors, students), and commercial application.
Key Design Points
High performance STM32H743 Processor with more computing power & RAM
Build-in Buzzer,Build-in RGB LED,support Independent external Safety Button,With Plastic Case
New cost-effective design with low-profile form factor
Newly designed integrated vibration isolation system to filter out high frequency vibration and reduce noise to ensure accurate readings
IMUs are temperature-controlled by onboard heating resistors, allowing optimum working temperature of IMUs
Technical Specification
Processors & Sensors
FMU Processor: STM32H743 32 Bit Arm® Cortex®-M7, 480MHz, 2MB memory, 1MB SRAM
IO Processor: STM32F103 32 Bit Arm® Cortex®-M3, 72MHz, 64KB SRAM
On-board sensors
Accel/Gyro: ICM-42688-P
Accel/Gyro: BMI055
Mag: IST8310
Barometer: MS5611
Electrical data
Voltage Ratings:
Max input voltage: 6V
USB Power Input: 4.75~5.25V
Servo Rail Input: 0~36V
Current Ratings:
TELEM1 Max output current limiter: 1.5A
All other port combined output current limiter: 1.5A
Mechanical data
Dimensions: 85 * 45 * 10 mm
Weight (Plastic Case) : 33g
Simple Collocation:
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO+2*PWM ModuIe+Safety Button+4G TF Card
High Collocation:
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO+2*PWM Module+I2C Expansion Board RGB LED Module+ Safety Button+4G TF Card
Simple Package:
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO +2*PWM Module+Safety Button+4G TF Card+M8N/M9N/M10 GPS+GPS Holder+Shock Absorber+PM02 Power Module(support 12S)
High Package:
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO+2*PWM Module+I2C Expansion Board +RGB LED Module+ Safety Button+4G TF Card+M8N/M9N/M10 GPS+GPS Holder+Shock Absorber+PM02 Power Module(support 12S)
433/915MHZ 100MW :
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO+ 2*PWM Module+ Safety Button+4G TF Card+ M8N/M9N/M10 GPS+GPS Holder+Shock Absorber+PM02 Power Module (support 12S)+Radio Telemetry V6 433/915MHZ 100MW
433/915MHZ 500MW :
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO+ 2*PWM Module+ Safety Button+4G TF Card+ M8N/M9N/M10 GPS+GPS Holder+Shock Absorber+PM02 Power Module (support 12S)+Radio Telemetry V6 433/915MHZ 500MW
433/915MHZ 1000MW :
NEW ZD680 Full Carbon Fiber+ 4pcs BLHELI 40A Brushless ESC+
2Pairs 3K Carbon Fiber Propeller 1255 +4PCS 3508 380KV Motor +
PIXHAWK 6C PRO+ 2*PWM Module+ Safety Button+4G TF Card+ M8N/M9N/M10 GPS+GPS Holder+Shock Absorber+PM02 Power Module (support 12S)+Radio Telemetry V6 433/915MHZ 1000MW
NEW ZD680 Full Carbon Fiber
Product Overview: FPV New F680 All 3K Carbon Fiber ZD 680 Foldable Arm Aircraft Frame Kit
High-Performance Design: A frame kit crafted for drone enthusiasts and professionals, made from high-strength 3K carbon fiber for exceptional durability and lightweight performance.
Foldable Arm Structure: Features a unique foldable arm design with 16MM carbon fiber tubes, allowing quick collapsing and deployment for enhanced portability and storage convenience while maintaining structural stability during flight.
Robust Body: Constructed with a 2MM carbon fiber body, ensuring strong support and rigidity.
Flight Control Recommendation: We recommend pairing with the PIXHAWK flight control system, renowned for its advanced navigation and stability, making the F680 ideal for FPV racing, aerial photography, and custom drone projects.
Recommended Configuration:
Flight Controller: PIXHAWK flight control system, offering precise navigation and stable performance.
ESC: 40A Electronic Speed Controller, ensuring reliable power management.
Motor: 3508 380KV motors, delivering powerful thrust and high efficiency.
Propeller: 12-inch (1255) propellers, achieving a perfect balance of lift and agility.
Battery: Supports 4S to 6S LiPo batteries, meeting diverse flight duration needs.
Key Benefits:
Material Strength: Benefits from the toughness of 3K carbon fiber and the convenience of foldable 16MM arms, combined with the rigidity of a 2MM carbon fiber body.
Versatile Application: An ideal platform for a wide range of applications, whether for racing enthusiasts or aerial photography experts.
Customizable Solution: Provides a high-quality, customizable drone solution for various projects.
M8N GPS:
M9N GPS Module
M9N is a GPS module commonly used in unmanned aerial vehicles, with the following characteristics and applications:
High precision positioning: The M9N adopts advanced GNSS technology, supports multiple satellite navigation systems, and can provide high-precision position positioning information. For unmanned aerial vehicles, it can achieve accurate positioning and navigation.
Multi system support: The M9N supports multiple satellite navigation systems, including GPS, GLONASS, Galileo, BeiDou, etc. This allows drones to receive multiple satellite signals simultaneously, improving positioning accuracy and reliability.
Quick positioning: M9N has fast cold start and hot start times, which can quickly obtain satellite signals and perform positioning, making it crucial for the rapid takeoff and task execution of unmanned aerial vehicles.
M9N can search for more satellites outdoors with higher accuracy, faster search speed, and better stability.(The specific number of star searches is determined by the environment at that time.)
The M10 GPS uses multi-constellation GNSS powered by u-blox M10 series, a concurrent GNSS receiver which can receive and track multiple GNSS systems. Owing to the multi-band RF front-end architecture all four major GNSS constellations, GPS,Galileo, GLONASS and BeiDou can be received concurrently.
It also comes with the IST8310 compass.This module ships with a baud rate of 115200 5Hz.
The high-gain 25 x 25 mm patch antenna provides excellent performance and the omnidirectional antenna radiation pattern increases flexibility for device installation. It features active circuitry for the ceramic patch antenna, rechargeable backup battery for warm starts.
Firmware Support for M10 GPS:
PX4 1.14, ArduPilot 4.3, or newer is required.
-
Specification
4PCS 3508 380KV Motor
Color Classification:Black
Motor Technical Parameters:
KV Value:KV380
Model:MX3508
Motor Diameter:42mm
Motor Length (No Shaft):24mm
Stator Diameter:35mm
Stator Length:8mm
Shaft Diameter:4mm
Weight:90g
Recommended Battery:4-6 Cells
Idle Current:0.3A
Top Mounting Hole:12mm x 12mm
Bottom Mounting Hole:25mm x 25mm
Suitable for:
Quadcopters
Hexacopters
Octocopters
Agricultural drones (plant protection machines)
Regarding Dynamic Balance:
We will test each motor before shipping to ensure it meets our factory standards. So, you don't need to worry about dynamic balance.
Note:No 3-socket pad is provided. Please refer to the diagram for specific components.
MX3508 Motor Features:
Flat design
Multiple slot extreme outer brushless motor
High torque and efficiency
Competitive price
Compatible with most market-leading drone frames (with multiple mounting holes)
Aesthetically pleasing design
Propeller Installation:
We use a hub-less propeller installation method, which provides more stability. The carbon propellers are installed without using propeller clamps, ensuring better protection and preventing damage.
Motor Dynamic Test Results:
Our motors have been tested by multiple professional drone photographers and videographers, and they all received excellent feedback.
Features:
2Pairs T-Motor 3K Carbon Fiber Propeller 1255
